Branch Crusher with R4105Z Turbocharged (74kw) Matching Power

1set
MOQ
Negotiable
Price
Branch Crusher with R4105Z Turbocharged (74kw) Matching Power
Features Gallery Product Description Request A Quote
Features
Specifications
Type: Branch Crusher
Cutter Diameter: 230mm
Host Speed: 1800 R/min
Discharge Height: 4m
Matching Power: R4105Z Turbocharged (74kw)
Mobile Form: Foldable Hand Crank Jack, Slipper Type
Brand: Keli
Application: Brick Making
Voltage: 220v 380v 415v
Customization: OEM ODM
High Light:

OEM hammer mill crusher

,

ODM hammer mill crusher

,

electric laboratory crusher

Basic Infomation
Place of Origin: China
Brand Name: KELI
Certification: ISO9001
Model Number: HY-6145
Payment & Shipping Terms
Packaging Details: Container
Delivery Time: 15-35days
Payment Terms: L/C, T/T
Supply Ability: 100sets/month.
Product Description

Branch Crusher with R4105Z Turbocharged (74kw) Matching Power



Model HY-6130 HY-6145
Cutter diameter (mm) 300 500
Cutting System Rolling longitudinal cutting Rolling longitudinal cutting
Feeding stall In-Stop-Reverse, 3 gears manual control In-Stop-Reverse, 3 gears manual control
Host speed (r/min) 2200 1800
Generator power (W)

600

600

Feeding roller diameter (mm) 280 600
Cutter length (mm) 300 230
Machine weight (kg) 800 2800
Discharge height (m) 2.5 4
Productivity (t/h) 1-2 3-5
Feeding throat size (mm) 300*200 450*380
Battery specifications 12V 105AH 24V 105AH
Start-up method Electric start Electric start
Matching power 32HP diesel engine R4105Z Turbocharged (74kw)
Discharge system Free 360° rotation with automatic injection discharge Free 360° rotation with automatic injection discharge
Mobile form Foldable hand crank jack, slipper type Foldable hand crank jack, slipper type
Number of cutters

Dynamic knife 3 pieces

fixed knife 1 piece

Dynamic knife 6 pieces

fixed knife 1 piece



Product Advantage Hydraulic feeding system
  • The pressure roller is automatically adjusted in height and hydraulically fed, with reasonable structure and automatic feeding, which is safe and convenient.
High strength tooth roll
  • It has the characteristics of wear resistance and high temperature resistance, which increases the stability and reliability of the machine, prolongs the service life and increases the operating efficiency.
Brand car hub wheel
  • Equipped with branded car wheel tires, which are durable and reliable.
Manganese steel hob
  • The blade is made of manganese steel.
  • The knife is tough, wear-resistant, sharp in cutting, not easy to rust, corrosion-resistant, and has a longer service life than ordinary steel knives.



Scope of application
  • It is mainly used for cattle and sheep feed, returning to the field for fertilizer, wood factory, edible fungus base material, mechanism charcoal, Buddha incense factory, mushroom cultivation.
  • It is widely used in various occasions with strong adaptability.



Performance characteristics

  • Air flow impact, strong power, complete crushing.
  • Real material, solid and durable, beautiful appearance
  • Reasonable structure, simple operation, 360° automatic material spray
  • Traction type mobile, fearless of a variety of terrain, strong adaptability



Product Details

Branch Crusher with R4105Z Turbocharged (74kw) Matching Power 0
