Mill Crusher KL-701-1E Hand Push Pulverizer Cutter Speed 3000rpm

Mill Crusher KL-701-1E Hand Push Pulverizer Cutter Speed 3000rpm
Features Gallery Product Description Request A Quote
Engine Model: 188F Diesel Engine
Engine Capacity: 389cc
Output Power: 13hp
Branch Diameter: 3-100mm
Outlet: Upper Discharge
Start Method: Electric Start
Fuel Type: 0#diesel Fuel
Type: Hand Push Pulverizer
Brand: Keli
Application: Brick Making
Voltage: 220v 380v 415v
Customization: OEM ODM
High Light:

OEM hammer mill crusher


ODM hammer mill crusher


electric laboratory crusher

Basic Infomation
Place of Origin: China
Brand Name: KELI
Certification: ISO9001
Model Number: KL-701-1E
Payment & Shipping Terms
Packaging Details: Container
Delivery Time: 15-35days
Payment Terms: L/C, T/T
Supply Ability: 100sets/month.
Product Description

Mill Crusher KL-701-1E Hand Push Pulverizer Cutter Speed 3000rpm


Main technical parameters

Model KL-701-1E diesel (electric start)



(hand start)



(hand start)


diesel (electric start)


(power optional)


gasoline (hand start)

Branch diameter(mm) 3-100 3-100 3-150 3-150 3-120 3-60
Paring knife(mm) 5.5*300 5.5*300 5.5*300 5.5*300 7.5*56*300 5.5*300
Cutter speed(rpm) 3000 2700 3600 3000 2600 2800
Outlet Upper discharge Upper discharge Upper discharge Upper discharge Upper discharge + bottom discharge Upper discharge
Engine model


diesel engine

Single-cylinder four-stroke air-cooled engine192F Single-cylinder four-stroke air-cooled engine192F


diesel engine


Gasoline and diesel/7.5kw motor

Single-cylinder four-stroke air-cooled engine170F
Engine capacity(cc) 389 420 420 430cc/7.5kw 420cc/7.5kw 208
Output Power(HP) 13 18 18 13 18 7.5
Diesel capacity(L) 5.5 6.5 6.5 6.5 6.5 3.6
Oil capacity(L) 1.5 1.1 1.1 1.1 1.1 0.6
Start method Electric start Hand pull recoil start Hand pull recoil start Electronic ignition Electronic ignition Hand pull recoil start
Fuel type 0#diesel fuel 92#Unleaded gasoline 92#Unleaded gasoline 0#diesel fuel 0#diesel fuel /92#gasoline 92#gasoline
G.W/N.W(kgs) 200/180 180/160 200/190 200/190 240/220 130/120
Package Size(cm) 122*58*96 122*58*96 155*80*125 155*80*125 122*58*96 113*41*82

Scope of application

  • Widely used in various occasions, strong adaptability.
  • Mainly used for cattle and sheep feed, edible fungus base material, also used as fertilizer, mechanism charcoal, Buddhist incense factory, timber factory, mushroom cultivation.


  • Hand-push movement, adapt to various terrains
  • Reasonable structure, simple operation, stable output
  • Airflow impact, strong power, complete crushing
  • Real materials, stable and durable, beautiful appearance

Mill Crusher KL-701-1E Hand Push Pulverizer Cutter Speed 3000rpm 0


Crushing principle: By combining a rapidly rotating blade with a sharp blade, various branches and plants can be crushed (branches, leaves, straw, etc.). Compared to incineration treatment, crushing treatment is more environmentally friendly, and waste can also be reused and crushed as fertilizer, returned to the field, culture medium, etc

The shredder is suitable for shredding residual branches, branches, and leaves in orchards, forest factories, tea factories, nurseries, gardens, and other fields. Due to its convenient use, it is suitable for shredding residual branches, leaves, and bark in parks, campuses, corporate units, and urban communities. It can be used as a mushroom base material, safe, reliable, practical, with high crushing efficiency and good effect. It is an agricultural equipment.
