Mill Crusher 701-1E Hand Push Pulverizer With 188F Diesel Engine

1set
MOQ
Negotiable
Price
Mill Crusher 701-1E Hand Push Pulverizer With 188F Diesel Engine
Features Gallery Product Description Request A Quote
Features
Specifications
Type: Hand Push Pulverizer
Branch Diameter: 3-100mm
Paring Knife: 5.5*300mm
Cutter Speed: 3000rpm
Outlet: Upper Discharge
Engine Capacity: 389cc
Brand: Keli
Application: Brick Making
Voltage: 220v 380v 415v
Customization: OEM ODM
High Light:

OEM hammer mill crusher

,

ODM hammer mill crusher

,

electric laboratory crusher

Basic Infomation
Place of Origin: China
Brand Name: KELI
Certification: ISO9001
Model Number: 701-1E
Payment & Shipping Terms
Packaging Details: Container
Delivery Time: 15-35days
Payment Terms: L/C, T/T
Supply Ability: 100sets/month.
Product Description

Mill Crusher 701-1E Hand Push Pulverizer With 188F Diesel Engine



The main technical parameters

Model 701-1E diesel (electric start)

701

gasoline

(hand start)

703

gasoline

(hand start)

703-1E

diesel (electric start)

702

(power optional)

704C

gasoline (hand start)

Branch diameter(mm) 3-100 3-100 3-150 3-150 3-120 3-60
Paring knife(mm) 5.5*300 5.5*300 5.5*300 5.5*300 7.5*56*300 5.5*300
Cutter speed(rpm) 3000 2700 3600 3000 2600 2800
Outlet Upper discharge Upper discharge Upper discharge Upper discharge Upper discharge + bottom discharge Upper discharge
engine model

188F

diesel engine

Single-cylinder four-stroke air-cooled engine192F Single-cylinder four-stroke air-cooled engine192F

188F

diesel engine

192F

Gasoline and diesel/7.5kw motor

Single-cylinder four-stroke air-cooled engine170F
engine capacity(cc) 389 420 420 430cc/7.5kw 420cc/7.5kw 208
Output Power(HP) 13 18 18 13 18 7.5
Diesel capacity(L) 5.5 6.5 6.5 6.5 6.5 3.6
oil capacity(L) 1.5 1.1 1.1 1.1 1.1 0.6
start method electric start Hand pull recoil start Hand pull recoil start electronic ignition electronic ignition Hand pull recoil start
fuel type 0#diesel fuel 92#Unleaded gasoline 92#Unleaded gasoline 0#diesel fuel 0#diesel fuel /92#gasoline 92#gasoline
G.W/N.W(kgs) 200/180 180/160 200/190 200/190 240/220 130/120
Package Size(cm) 122*58*96 122*58*96 155*80*125 155*80*125 122*58*96 113*41*82


Mill Crusher 701-1E Hand Push Pulverizer With 188F Diesel Engine 0



Scope of application:

Widely used in various occasions, strong adaptability. Mainly used for cattle and sheep feed, edible fungus base material, also used as fertilizer, timber factory, Buddhist incense factory, mechanism charcoal, mushroom cultivation.



Why Choose Us?

  • Since the manufacturing team all possesses years of experience, KELI can provide competitive price and superior service.
  • To provide you with the most professional products and services
  • Since the manufacturing team all possesses years of experience, KELI can provide competitive price and superior service.
  • Have our own professional service team, not outsourcing service to ensure customer satisfaction
  • We have our own modern standard factory and adopt "6s" quality & cost control system, can customize all machinery at the most reasonable price.
  • We pay much more attention to details!
  • We adopt advanced technology!
  • Based on the wide product range, we offer the best One-Stop sourcing service and all-around after-sales service .
  • All KELI team strictly follow our values,vision and mission by action not by words or advertising
