KL-420 Square Mouth Impact Mill Rock Crusher Processing Efficiency 1200kg

KL-420 Square Mouth Impact Mill Rock Crusher Processing Efficiency 1200kg
Features Gallery Product Description Request A Quote
Processing Efficiency: 1200kg
Material Port Diameter: Φ150*150mm
Machine Weight: 130kg
Type: Square Mouth Crusher Mill Crusher
Brand: Keli
Application: Brick Making
Voltage: 220v 380v 415v
Customization: OEM ODM
High Light:

square coal crusher hammer


1200kg coal crusher hammer


150mm impact mill rock crusher

Basic Infomation
Place of Origin: China
Brand Name: KELI
Certification: ISO9001
Model Number: KL-420
Payment & Shipping Terms
Packaging Details: Container
Delivery Time: 15-35days
Payment Terms: L/C, T/T
Supply Ability: 100sets/month.
Product Description

Square Mouth Crusher Processing Efficiency 1200kg Mill Crusher


Square mouth crusher

Alloy moving knife:

  • Alloy knife is used, which is tough, wear-resistant, sharp cutting, not easy to rust, corrosion-resistant, long service life, and improves the efficiency of the pulverizer.

High-precision bearings:

  • The main part is handled by dynamic balancing equipment, and the weight error in each direction of the machine is very small, which ensures the smooth operation of the machine, improves production efficiency, prolongs the service life, low cost, and high output.

Thickened cutterhead:

  • It is composed of thickened steel plates, which changes the original fragile characteristics and increases the service life of the machine. The entire cutterhead operates smoothly and plays the role of secondary crushing.

Carbon-structured steel hammer:

  • Made of carbon-structured steel, it can crush wood chips multiple times to improve the crushing rate. The hammer can be used on both sides, and the hammer can be replaced by itself, but only in the same position.
Model KL-420

Diesel horsepower

hp 15

Machine weight

kg 130
Number of blades alloy 4
Processing efficiency kg 1200
Power kw 11

Material port diameter

mm Φ150*150

Spindle speed

r/min 2800


  • Traction-type movement, no fear of various terrains, strong adaptability


  • Airflow impact, strong power, complete crushing


  • Reasonable structure, simple operation, upper and lower discharge


  • Real materials, stable and durable, beautiful appearance

Scope of application

  • Widely used in various occasions, strong adaptability.


  • Mainly used for cattle and sheep feed, edible fungus base material, also used as fertilizer, mechanism charcoal, Buddhist incense factory, timber factory, mushroom cultivation.
Product Show

KL-420 Square Mouth Impact Mill Rock Crusher Processing Efficiency 1200kg 0


Other Models
Model KL-500 KL-600 KL-700 KL-900 KL-1000
Diesel horsepower hp 25 32 45 50 55
Machine weight kg 210 320 450 650 800
Number of blades alloy 4 4 6 8 8
Processing efficiency kg 1500 2000 2500 3000 4000
Power kw 18.5 30 37 55 75+7.5
Material port diameter mm Φ200*200 Φ250*250 Φ300*300 Φ350*350 Φ400*400
Spindle speed r/min 2800 2700 2100 2000 2000
