Mill Crusher Square Mouth Crusher 2000kg Processing efficiency

Mill Crusher Square Mouth Crusher 2000kg Processing efficiency
Features Gallery Product Description Request A Quote
Type: KL-600 Square Mouth Crusher
Power: 30kw
Machine Weight: 320kg
Spindle Speed: 2700r/min
Number Of Blades: 4
Material Port Diameter: Φ250*250mm
Brand: Keli
Application: Brick Making
Voltage: 220v 380v 415v
Customization: OEM ODM
High Light:

OEM hammer mill crusher


ODM hammer mill crusher


electric laboratory crusher

Basic Infomation
Place of Origin: China
Brand Name: KELI
Certification: ISO9001
Model Number: KL-600
Payment & Shipping Terms
Packaging Details: Container
Delivery Time: 15-35days
Payment Terms: L/C, T/T
Supply Ability: 100sets/month.
Product Description

Mill Crusher Square Mouth Crusher 2000kg Processing efficiency

The main technical parameters



Spindle speed (r/min) 2700
Number of blades (alloy) 4
Processing efficiency (kg) 2000
Material port diameter (mm) Φ250*250
Power (kw) 30
Diesel horsepower (hp) 32
Machine weight (kg) 320

Scope of application:

  • Widely used in various occasions, strong adaptability.
  • Mainly used for cattle and sheep feed, Buddhist incense factory, edible fungus base material, mechanism charcoal, also used as fertilizer, timber factory, mushroom cultivation.

Square mouth crusher

  • Carbon-structured steel hammer: made of carbon-structured steel, it can crush wood chips multiple times to improve the crushing rate. The hammer can be used on both sides, and the hammer can be replaced by itself, but only in the same position.
  • Alloy moving knife: Alloy knife is used, which is tough, wear-resistant, sharp cutting, not easy to rust, corrosion-resistant, long service life, and improves the efficiency of the pulverizer.
  • High-precision bearings: The main part is handled by dynamic balancing equipment, and the weight error in each direction of the machine is very small, which ensures the smooth operation of the machine, improves production efficiency, prolongs the service life, low cost, and high output.
  • Thickened cutterhead: It is composed of thickened steel plates, which changes the original fragile characteristics and increases the service life of the machine. The entire cutterhead operates smoothly and plays the role of secondary crushing.


Mill Crusher Square Mouth Crusher 2000kg Processing efficiency 0
The square mouth crusher is mainly suitable for crushing medium to low hardness materials, and can crush granular refined feed such as corn, sorghum, beans, and cakes; It is also possible to crush block like grass, dry weeds, sweet potato seedlings, peanut seedlings, rice straw, dry grain straw, etc. into coarse feed; Applied to small and medium-sized pig farms, pig farmers, and sideline processing households in rural areas, it is an ideal, effective, and economical equipment. Adding an automatic feeding crusher to the power electric automatic feeding crusher will affect the production, but at the same time, the power consumption will correspondingly increase, and vice versa.
Other Model
Model KL-420 KL-500 KL-700 KL-900 KL-1000
Spindle speed(r/min) 2800 2800 2100 2000 2000
Number of blades (alloy) 4 4 6 8 8
Processing efficiency(kg) 1200 1500 2500 3000 4000
Material port diameter(mm) Φ150*150 Φ200*200 Φ300*300 Φ350*350 Φ400*400
Power(kw) 11 18.5 37 55 75+7.5
Diesel horsepower(hp) 15 25 45 50 55
Machine weight(kg) 130 210 450 650 800
