250mm Clay Brick Making Machine With Dryer 18-40t/H Hammer Crusher

250mm Clay Brick Making Machine With Dryer 18-40t/H Hammer Crusher
Features Gallery Product Description Request A Quote
Productivity: 18-40t/h
Dimensions: 1310*1180*1310mm
Type: Clay Brick Making Machine
Feed Particle Size: 250mm
Brand: Keli
Application: Brick Making
Voltage: 220v 380v 415v
Voltage: 220v 380v 415v
Customization: OEM ODM
High Light:

250mm clay brick mixer machine


40t/h clay brick making machine with dryer


18t/h clay brick making machine with dryer

Basic Infomation
Place of Origin: China
Brand Name: KELI
Certification: ISO9001
Model Number: PC800x600
Payment & Shipping Terms
Packaging Details: Container
Delivery Time: 15-35days
Payment Terms: L/C, T/T
Supply Ability: 100sets/month.
Product Description

Clay Brick Making Machine Feed Particle Size 250mm Hammer Crusher


The hammer crusher is a machine that crushes materials in the form of impact, in both single and double rotor form. It is a crusher for direct crushing of materials with a maximum size of 600-1800 mm to a section of 25 or less. The hammer crusher is used in the cement, chemical, electric power and metallurgical industries to crush medium and fine materials of medium hardness, such as limestone, slag, coke, coal and other materials.

Hammer crushers are available in single and double rotor versions. The single rotor is subdivided into reversible and irreversible types. Single rotor hammer crushers and ring hammer crushers are widely used.

Components of the hammer crusher include the box, rotor, hammer head, impact liner, screen plate, etc.


The hammer crusher's main working part is the rotor with hammers (also called hammer head). It is crushed by the striking, impacting, shearing and grinding action of the hammers moving at high speed. Moreover, the rotor is equipped with a sieve plate in the lower part of the rotor, and those particles smaller than the size of the sieve are discharged through the sieve plate. It is suitable for crushing minerals of various brittle materials. Suitable materials for crushing are coal, salt, baiya, gypsum, alum, brick, tile, limestone, etc. The compressive strength of the hammer crusher material is not more than 100 MPa and the humidity is not more than 15%. It is available for use as crushing equipment for materials such as stone crushing, rock crushing, mining crushing, plastic crushing, garbage crushing, etc.


Model PC800x600
Number of motor poles 4
Power (kw) 30-55
Dimensions (mm) 1310*1180*1310
Feed particle size (mm) 250
Machine weight (kg) 3200
Discharge particle size (mm) 35
Productivity (t/h)




Product Show

250mm Clay Brick Making Machine With Dryer 18-40t/H Hammer Crusher 0


Support and Services:

We provide technical support and services for Mill Crusher products. Our technical support team is available 24/7 to answer questions and provide guidance on installation, operation, and troubleshooting. We also offer regular maintenance services to ensure that your Mill Crusher is running at peak performance. Our experienced technicians are always on hand to provide advice and assistance. If you have any issues with your Mill Crusher, feel free to contact us and we'll be glad to help.
